DougM Messages: 5 Registered: February 2014 Location: United States
Esquire
Hello All,
Wayne's posts and helpful replies convinced me that my speaker build should be 3 Pi mains with flanking 3Pi subs. I'm working on the sub build first, and noticed that no crossovers arrived with the drivers for the subs. Research led me to believe that plate amps were of low quality, and I didn't think they'd sound good with my tube amp. Apparently active crossovers are the best option, and I got a deal on a demo model of the Rane 22S.
My next issue seems to be the balanced outputs of the Rane crossover. It looks like the easiest way to connect the balanced outputs of the Rane to my unbalanced Amp would be to have Blue Jeans Cable send me the correctly configured cables. Does anyone know if I should use #4 or #6 from the attachments?
gofar99 Messages: 1949 Registered: May 2010 Location: Southern Arizona
Illuminati (5th Degree)
Hi, No, but you will lose the benefits of the balanced line configuration (low noise, immunity to EMI). An alternative is something called a Direct Box from the Pro side of the house. They come in all sorts of configurations and will provide the connection you need. Both passive and active are available.
Wayne Parham Messages: 18787 Registered: January 2001
Illuminati (33rd Degree)
Remember that balanced pairs are like speaker outputs, with a "+" and a "-", each signal being the compliment of the other. Unbalanced signals are referenced to ground or some other "zero" reference. The information is the same either way, as is the content and everything else. So nothing is lost or gained with respect to information or signal content. Its just a different interface. The main thing that makes balanced attractive is common mode rejection. Any signal coupled into the wire pair will be cancelled at the input(s), since each is the opposite of the other. Anything that is common to both is cancelled.
DougM Messages: 5 Registered: February 2014 Location: United States
Esquire
Hello Wayne and Bruce,
Thanks for all your help. I had quite a bit of catching up to do.
I ended up making some Ebay purchases, and the sound is great!
Adcom GFA-555 amp
Rane Active Crossover
Rane Balance Buddy
I used copper laminate on the subs, and they came out pretty well. We've had quite a few cloudy days lately and the speaker didn't show up well in my photo, so I included a photo of the top of one of the speakers so you can see how beautiful they came out.
